This CNC engraving machine is constructed of an aluminum alloy. It has a GRBL control board, which allows you to operate efficiently with or without a computer. It is an excellent tool for engraving various types of plastics, soft metal, wood, PVC, and so on. It is a fantastic low-cost self-learning engraving tool.
CNC 2418 Router Machine: The CNC 2418 PRO is an improved version of the CNC 2418 CNC. For your convenience, we supply a thorough user handbook, assembly instructions, and an installation video. Install the engraving machine according to the instructions. You can engrave plastics, soft aluminum, acrylics, PVC, PCB, and many more materials. This product does not include a laser head, which must be purchased separately.
Large Working Area: This engraving machine has an effective engraving area of 9.4(X) x 7.1(Y) x 1.8(Z) inches. To achieve plane engraving, three refined axes are devised. The axes can be manipulated manually with the knob, making carving tool settings easier. The screw rods used in the drive units are made of stainless steel. It employs double copper nuts to eliminate round-trip mistakes.
This CNC engraving machine has three stepper motors (1.3A; 12V; 0.25 Nm torque) and 775 DC(12-24V) 24V spindle motors with a rotational speed of 10,000 r/min. Furthermore, the engraver is compatible with Windows 7, Windows 8, Windows 10, Linux, macOS, and other software for direct importing. NC/.txt/.tape/.code format files for engraving.
Control Board Upgrade: The integrated GRBL control has complete capability and stability. And the advantages of the offline controller are as follows: 1. There is no need to connect to the computer. 2. Selection of offline files for engraving at will. 3. Manually adjust the X, Y, and Z axes' positions as the engraving beginning point, and turn the spindle on and off. 4. Extreme precision: less than 0.003 inches.
Sturdy Material: The frame is mostly constructed of aluminum alloy components that are both strong and precise. The triangular side support helps increase the x-axis motion precision. Furthermore, it is tough enough to resist the rigors of all-day use on a regular basis.
Specifications
Effective Working Area(X x Y x Z): 9.4 x 7.1 x 1.8 inch/ 24 x 18 x 4.5 cm
Materials: Aluminium Alloy
Input Power: DC 24V, 5A
Driving Units: Stainless Steel Screws
Spindle Speed: 10,000 rpm
Stepping Motor: 12V; Torque: 0.25 N/m
Control Software: GRBL Control
Positioning Accuracy: 0.003 in / 0.08 mm
Item Dimension: 15.7 x 15 x 11.5 inch/ 40 x 38.3 x 29.2 cm
Package Content
1 x 2418 CNC Router Kit
1 x Offline Controller
1 x U-Disk (Software & Instruction)
1 x Set of Milling Cutter
1 x Cable
1 x Brush
1 x Power Supply
1 x Manual
Condition: New
Shipping: Nationwide
Delivery: 2 to 5 business days
